Handicare

Handicare 1100 Stair Lift

Handicare 1100 Stair Lift

This product cannot be ordered online. Please call us at 1-833-RAMP-OUTLET and a sales agent will assist you with ordering.

If you have any questions, please do not hesitate to contact National Ramp Outlet Plus at 833-RAMP-OUTLET and we will be more than happy to help.

Design

Our design team has put a lot of thought into the Handicare 1100 Style. We have worked hard to deliver a stairlift that not only provides your customer with a great solution but is also good for our trade partners to stock, install and maintain. For example, making batteries easier to replace was a must. The Handicare 1100 Style is a new, unique and patent 4-wheel drive system based on friction drive.  Compared to all other straight stairlifts there is no greasy gear rack on the rail.

Standard features

  Retractable seat belt

  Fold up seat, armrests and footrest

  Key operated switch

  Emergency stop

  Soft start and soft stop

  Automatic stop at the top and bottom of the stairs

  Footrest safety edges

  Full cover safety edges

  Wall-mounted hand held remote controls at the top and bottom of the stairs

  2 rail sections, each 2.35m / 92.52 in

  Continuous charge

Available options

  Zero intrusion

  Carpet spacer

Slide Track

  Longer rails up to 7m / 275.59 in

On/off switch

  Powered swivel seat

Velcro belt

  Powered footrest

  Easy hinge



Specifications

Power supply

90-230V~

Frequency

50/60Hz

Current

1.0 Amp

Power consumption

0-36 Watt

Max. load (inclination 25°-45°)

140 kg [308 lbs]

Max. load (inclination 45°-50°)

130 kg [286 lbs]

Max. load Easy hinge

see standard configuration

Max. load Slide Track

120 kg

Speed **

0.15 m/sec (max)

Noise

56 dB

Minimum stair length

3 steps*

Standard rail length

4700 mm (2 x 2350 mm / 2x 92.52 in)

Maximum rail length

7050 mm (3 x 2350 mm / 2x 92.52 in)

Rail colour

aluminium anodised, self colour

Inclination standard

25˚ - 50˚

Inclination easy hinge

25˚ - 50˚

Inclination zero intrusion

25˚ - 45˚

Inclination Slide Track

37˚ - 50˚

Ambient temperature

0° - 40° Celsius

              Relative humidity                                  20% - 80%
